| Nominal size Inch | Outside dia | 5S | 10S | 20S | 30S | 40S | 60S | 80S | 110S | 120S | 140S | 160S | XS | XXS |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1/8" | 10.3 | - | 1.24 | - | - | 1.73 | - | 2.4 | - | - | - | 1.73 | 2.41 | - |
| 1/4" | 13.7 | -1.7 | 1.65 | - | - | 2.24 | - | 3.02 | - | - | - | 2.24 | 3.02 | - |
| 3/8" | 17.1 | - | 1.65 | - | - | 2.31 | - | 3.2 | - | - | - | 2.31 | 3.2 | - |
| 1/2" | 21.3 | 1.65 | 2.11 | - | - | 2.77 | - | 3.73 | - | - | - | 2.77 | 3.73 | 7.47 |
| 3/4" | 26.7 | 1.65 | 2.11 | - | - | 2.87 | - | 3.91 | - | - | - | 2.87 | 3.91 | 7.82 |
| 1" | 33.4 | 1.65 | 2.77 | - | - | 3.38 | - | 4.55 | - | - | - | 3.38 | 4.55 | 9.09 |
| 11/4" | 42.2 | 1.65 | 2.77 | - | - | 3.56 | - | 4.85 | - | - | - | 3.56 | 4.85 | 9.7 |
| 11/2" | 48.3 | 1.65 | 2.77 | - | - | 3.68 | - | 5.08 | - | - | - | 3.68 | 5.08 | 10.15s |
| 2" | 60.3 | 1.65 | 2.77 | - | - | 3.91 | - | 5.54 | - | - | - | 3.91 | 5.54 | 11.07 |
| 21/2" | 73 | 2.11 | 3.05 | - | - | 5.16 | - | 7.01 | - | - | - | 5.16 | 7.01 | 14.02 |
| 3" | 88.9 | 2.11 | 3.05 | - | - | 5.49 | - | 7.62 | - | - | - | 5.49 | 7.52 | 15.24 |
| 31/2" | 101.6 | 2.11 | 3.05 | - | - | 5.74 | - | 8.08 | - | - | - | 5.74 | 8.08 | - |
| 4" | 114.3 | 2.11 | 3.05 | - | - | 6.02 | - | 8.56 | - | 11.13 | - | 6.02 | 8.56 | 17.12 |
| 5" | 141.3 | 2.77 | 3.4 | - | - | 6.55 | - | 9.52 | - | 12.07 | - | 6.55 | 9.53 | 18.05 |
| 6" | 168.3 | 2.77 | 3.4 | - | - | 7.11 | - | 10.97 | - | 14.27 | - | 7.11 | 10.97 | 21.95 |
| 8" | 219.1 | 2.77 | 3.76 | - | 6.35 | 8.18 | 10.31 | 12.07 | 15.09 | 16.26 | 20.62 | 8.18 | 12.07 | 22.23 |
| 10" | 273 | 3.4 | 4.19 | - | 6.35 | 9.27 | 12.7 | 15.09 | 18.26 | 21.44 | 25.4 | 9.27 | 12.7 | 25.4 |
| 12" | 323.8 | 3.96 | 4.57 | - | 6.35 | 10.31 | 14.27 | 17.48 | 21.44 | 25.4 | 28.58 | 9.35 | 12.07 | 25.4 |
| 14" | 355.6 | 3.96 | 4.78 | 6.35 | 7.92 | 11.13 | 15.09 | 19.05 | 23.83 | 27.79 | 31.75 | 9.53 | 12.7 | - |
| 16" | 409.4 | 4.19 | 4.78 | 6.35 | 7.92 | 12.7 | 16.66 | 21.44 | 26.19 | 30.96 | 36.53 | 9.53 | 12.07 | - |
| 18" | 457.2 | 4.19 | 4.78 | 6.35 | 7.92 | 14.27 | 19.05 | 23.83 | 29.36 | 34.92 | 39.67 | 9.53 | 12.7 | - |
| 20" | 508 | 4.79 | 5.54 | 6.35 | 9.53 | 15.09 | 20.62 | 26.19 | 32.54 | 38.1 | 44.45 | 9.53 | 12.07 | - |
| 22" | 558.8 | 4.79 | 5.54 | 6.35 | 9.53 | - | 22.23 | 28.56 | 34.93 | 41.28 | 47.63 | 9.53 | 12.7 | - |
| 24" | 609.6 | 5.54 | 6.35 | 6.35 | 9.53 | 17.48 | 24.61 | 30.96 | 38.89 | 46.02 | 52.37 | 9.53 | 12.07 | - |
| 26" | 660.4 | - | - | 7.92 | 12.7 | - | - | - | - | - | - | 9.53 | 12.7 | - |
| 28" | 711.2 | - | - | 7.92 | 12.7 | - | - | - | - | - | - | 9.53 | 12.7 | - |
| 30" | 762 | 6.35 | 7.92 | 7.92 | 12.7 | - | - | - | - | - | - | 9.53 | 12.7 | - |
| 32" | 812.8 | - | - | 7.92 | 12.7 | - | - | - | - | - | - | 9.53 | 12.7 | - |
| 34" | 863.6 | - | - | 7.92 | 12.7 | - | - | - | - | - | - | 9.53 | 12.7 | - |
| 36" | 914.4 | - | - | 7.92 | 12.7 | - | - | - | - | - | - | 9.53 | 12.7 | - |
